Specifications
Plasma Screen 42 inch Visual size (Diagonal), AC Drive type
Aspect ratio : 16:9
Optical filter coating
Display color : 16,770,000 colors 256 levels
RGB Input Terminals RGB 1 : mini D-SUB 15pin
RGB 2 : BNC (R,G,B, H/CS and V)
RGB 3 : Digital RGB (DVI 24+5pin: Not compatible with analog input.
Complies with DVI
Video : Analog 0.7Vp-p/75 Ohms (Positive)
: Sync. : Separate Sync. TTL level, 0.7 - 4.0Vp-p/75 Ohms..........BNC only
Horizontal Sync. (Positive/Negative)
Vertical Sync. (Positive/Negative)
: Composite Sync. TTL Level (Positive/Negative)
: Composite Sync. On Green Video 0.3Vp-p (Negative)
RGB Output Terminals BNC (R,G,B, H/CS and V)
THROUGH OUT RGB THROUGHOUT (RGB2 only)
Video Input Terminals 1.0Vp-p, 75 Ohms unbalanced (BNC-Jack), Composite video signal, Sync-negative.
VIDEO Y : 1.0Vp-p, 75 Ohms unbalanced, Sync-negative.
S-VIDEO C : 0.28Vp-p, 75 Ohms unbalanced, Color burst level.
Video Output Terminals
THROUGH OUT 1.0Vp-p, 75 Ohms unbalanced (BNC Jack), Composite video signal, Sync-negative.
THROUGH OUT (S-VIDEO) Y : 1.0Vp-p, 75 Ohms unbalanced, Sync-negative.
C : 0.28Vp-p, 75 Ohms unbalanced, Color burst level.
External Control mini D-SUB 15pin (IN/THROUGH OUT)
(IN/THROUGH OUT) Open/Short, RS-232C Control
Synchronization Range Horizontal : 15.5 to 68.7 KHz (automatic : step scan)
Vertical : 46.0 to 85.0 Hz (automatic : step scan)
Maximum Resolution RGB : 853( H) X 480(V) pixels
Power Supply 100-120 VAC, 50/60 Hz
Current Rating 5.6A (maximum)
Power consumption 430W (typical)
Dimensions 39.3(W) x 23.4(H) x 4.5(D) inches / 998(W) X 595(H) X114(D) mm
Weight 72.7lbs/33kg
Environmental Considerations Operating Temperature : 0 to 40
Humidity : 20 to 80%
Altitude : 0 to 6233 feet(1900m)
Storage Temperature : -10 to 50
Humidity : 10 to 90%
Altitude : 0 to 9842 feet(3000m)
Regulations : UL/C-ULApproved (UL 1950/CSA 950)
DOC Canada requirements
Meets FCC class A requirements
All specifications are subject to change without notice.
PlasmaSync 42PD2 (Model PX-42VP2A)
