Maintaining Your Network
28
NETGEAR DOCSIS 3.0 N450 Wi-Fi Data Gateway
View the Gateway Status
To see hardware and firmware details and basic status information about the gateway, use
the Modem Status screen.
To view the gateway status:
From the main menu, under Maintenance, select Modem Status.
The following screen displays.
The following table describes the fields displayed in this screen:
Modem field Description
Standard Specification
Compliant
DOCSIS 3.0
Hardware Version The hardware version of the gateway.
Software Version The version of firmware currently running on the gateway.
Cable MAC Address The MAC address used by the cable modem port of the gateway. This MAC
address might need to be registered with your cable service provider.
Device MAC Address The WAN MAC address used by the device.
Cable Modem Serial Number The serial number of the gateway hardware.
CM certificate If the cable modem certificate is installed, it is possible for the service
provider to upgrade your Data Over Cable service securely.
System Up Time Time since the last boot-up.
Network Access Shows whether traffic can be forwarded from the LAN to the network.
Cable Modem IP Address The current Internet IP address. If assigned dynamically and not connected
to the Internet, this field is blank.
