C 962 F1G1H181A495 CAPACITOR, 50V, 180pF 1
C 966 F1G1H561A496 CAPACITOR, 50V, 560pF 1
C 967 F1G1H151A495 CAPACITOR, 50V, 150pF 1
C 968 F1G1H470A542 CAPACITOR, 50V, 47pF 1
C 969 F1G1H331A496 CAPACITOR, 50V, 330pF 1
CF 1, 2, 3 D4CC1103A038 THERMISTOR 3
CN 2 K1MYL0B00004 CONNECTOR 1
CN 3 K1MYL0B00005 CONNECTOR, DIMM 1
CN 4 K1KA02BA0014 CONNECTOR 1
CN 5 K1MY52BA0190 CONNECTOR 1
CN 6, 21 K1KA08BA0014 CONNECTOR 2
CN 7 K1MN20BA0134 CONNECTOR 1
CN 8 K1NAF0D00003 CONNECTOR 1
CN 12 K1KB12A00099 CONNECTOR 1
CN 13 K1KY42B00001 CONNECTOR 1
CN 14 K1KA62B00003 CONNECTOR 1
CN 15 K1KA06BA0014 CONNECTOR 1
CN 16 K1FY104BA024 CONNECTOR, USB 1
CN 17 K1KY50AA0103 CONNECTOR 1
CN 18 K1KA05BA0014 CONNECTOR 1
CN 19 K1KB40AA0049 CONNECTOR 1
CN 22, 27 K1MN10BA0134 CONNECTOR 2
CN 23 K1FY165EA001 CONNECTOR 1
CN 24 K1KA30BA0060 CONNECTOR 1
CN 25 K1MN30AA0018 CONNECTOR 1
CN 26 K1MN12BA0160 CONNECTOR 1
CN 29 K1KA02BA0085 CONNECTOR 1
CN 801 K1KA10B00213 CONNECTOR 1
CN 802 K1KA06BA0128 CONNECTOR 1
D 2, 3, 9, 23, 42 MA2J72900L DIODE 5
D 4 MA3J741E0L DIODE 1
D
10, 806, 807, 809, 810,
812, 840, 845, 846
B0JCMD000014 DIODE 9
D
12, 13, 14, 15, 16, 17,
18, 21, 22, 24, 837, 838,
B0ADDH000004 DIODE 13
D 19, 20, 34 B0KB00000044 DIODE 3
D 33, 821, 823, 824 MA2S111-TX DIODE 4
D 38 B3ABB0000210 DIODE 1
D 39 B3AGB0000040 DIODE 1
D 40 B3ADB0000065 DIODE 1
D
801, 804, 827, 828, 829,
830, 835, 836
B0JCPD000023 DIODE 8
D 805, 808, 811 B0ADCJ000025 DIODE 3
D
813, 814, 815, 816, 817,
818, 819, 841
MAZ80620ML DIODE 8
D 820 B2ABAM000002 DIODE 1
D 825 MAZ81800ML DIODE 1
D 826 MAZ81200ML DIODE 1
D 832 B0JDRE000007 DIODE 1
D 833, 834 B0JDBE000002 DIODE 2
F 1, 2, 4, 5, 10 S K5H202Z00005 FUSE, 2A, 32V 5
F 3 S K5H402Z00003 FUSE, 4A, 32V 1
F 800, 801, 802 S K5H153A00001 FUSE, 15A, 65V 3
FL
1, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15, 16, 17,
18, 19, 20, 21, 22, 23,
24, 25, 26, 27, 28, 29,
31
,
33
,
34
,
35
,
36
,
37
F1H0J1050022 CAPACITOR, 6.3V, 1µF 32
FL 2, 3, 4 J0JDC0000038 CHIP BEADS 3
FL
38, 39, 40, 41, 42, 43,
44, 45, 46, 47, 48, 49,
50, 51, 52, 53, 54, 55
F1J0J4750019 CAPACITOR, 6.3V, 4.7µF 18
IC 1 C2GBD0000033 CPU 1
IC 2 C1CB00002734 TEMPERATURE SENSOR 1
IC 6 C0JBBZ000319 PLL 1
IC 7 C0JBAZ002192 IC 1
IC 9, 32, 42, 63, 71, 86, 819 C0JBAA000362 IC, LOGIC 7
IC 10 C1CB00002732 LAN CONTROLLER 1
