34
OPTION1 settings
OPTION1
COLOR CORRECTION
BACK COLOR
BLACK
SUB MEMORY LIST
DVI EDID
EDID2:PC
OFF
CONTRAST MODE
AUTO SIGNAL
SELECT RETRNENTER
COLOR CORRECTION
OFF : Standard setting
USER : The six colours of red, green, blue, cyan,
magenta and yellow can be adjusted
and registered for each of four signal
systems: Video, S-Video, RGB and
YPBPR.
Press the “ENTER” button to make the
detailed settings.
SELECT
RETRN
STORE
SUB MEMORY LIST
CONTRAST MODE
There are two modes for adjusting to the operating
environment.
NORMAL : The contrast is set to normal and the
brightness to maximum.
HIGH : The contrast is set to maximum and
the brightness to normal.
AUTO SIGNAL
The position where the screen is displayed can be
adjusted automatically without pressing the AUTO
SETUP button on the remote control each time
signals are input when signals are input frequently
such as when the projector is used at a conference.
ON : Auto setup is performed automatically
when the video signals of the images
being projected have changed.
OFF : The input auto setup function is set to
OFF.
BACK COLOR
You can set the colours of the screen when no
signal is input to the projector.
BLUE: Set screen colour to blue.
BLACK: Set screen colour to black.
DVI EDID
Set EDID to match the device connected.
SUB MEMORY LIST
Multiple sets of image adjustment data (PICTURE,
POSITION, ADVANCED MENU adjustment values)
for the same kind of signal can be registered.
Registering in sub memory
Select the sub memory number to be registered
using the button.
Press the ENTER button.
How to select sub memory
Select sub memory number (1 to 8) using the
buttons. Select “–” if you do not wish to
use the sub memory.
Press the ENTER button.
How to erase sub memory
Select sub memory number (1 to 8) corresponding
to sub memory to be erased using buttons.
Press the STD button.
When the indicator of sub memory to be erased
flashes, press the ENTER button.
• Sub memories range from 1 to 8.
Note
• You cannot select sub memory of a
different signal system.
Note
COLOR CORRECTION
RGB
R
0
0
0
0
0
G
0
Cy
B
Mg
Ye
SELECT ADJ RETRN
The current signal
system is displayed.
Mode
EDID1
EDID2:PC
Matching Signal
480p, 576p, 720/60p, 1080/60i,
1080/50i
VGA480/60, SVGA/60, XGA/60,
XGA/70, XGA/85, SXGA/60
