M61323SP/FP
REJ03F0201-0201 Rev.2.01 Mar 31, 2008
Page 11 of 19
Input Signal
SG No. Signals
SG1 Sine wave (f = 60 kHz, 0.7 V
P-P
(Amplitude variable) )
0.7 V
P-P
(variable)
SG2 Sine wave (f = 1 MHz, 0.7 V
P-P
(Amplitude variable) )
SG3 Sine wave (f = 10 MHz, 0.7 V
P-P
(Amplitude variable) )
SG4 Sine wave (f = 100 MHz, 0.7 V
P-P
(Amplitude variable) )
SG5 Sine wave (f = 250 MHz, 0.7 V
P-P
(Amplitude variable) )
SG6
0.7 V
P-P
DUTY 80%
fH = 60 kHz
0.7 V
P-P
SG7 Sync (fH = 60 kHz)
Amplitude variable
(Typ. = 0.3 V
P-P
)
4.5 µs
SG8
5 V
0 V
DUTY 50%
fH = 60 kHz
TTL
Typical Characteristics
Power Dissipation Pd (mW)
Ambient Temperature Ta (°C)
1250
1500
1750
0
250
500
750
1000
1250
1500
1750
0
250
500
750
1000
833
85
1603
−25 0 25 50 75 100 125 150 −25 0 25 50 75 100 125 150
Thermal Derating (M61323SP)
Power Dissipation Pd (mW)
Ambient Temperature Ta (°C)
640
Thermal Derating (M61323FP)
1068
