English > Main > Specifications > General Specifications
General
PowerSaver
Preset Timing
Modes
Design and specifications are subject to change without prior notice.
General
Model Name SyncMaster 172MP
LCD Panel
Size 17.0 inch (Diagonal)
Display area 337.92 (H) x 270.336.336 (V)
Pixel Pitch 0.264 (H) x 0.264 (V)
Type a-si TFT active matrix
Viewing Angle 170°(H) / 170° (V)
Synchronization
Horizontal 31 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16,194,277 Colors
Resolution
Optimum resolution 1280 x 1024@60Hz
Maximum resolution 1280 x 1024@75Hz
Input Signal, Terminated
RGB Analog, Composite H/V, 0.7Vp-p Positive at 75 ohm,
Separate H / V sync, TTL level positive or negative
TV / Video
Color system PAL, SECAM, NTSC 4.43
Sound system BG, DK, I, L
Video format CVBS, S-VHS
Maximum Pixel Clock
135 MHz
Power Supply
90 to 264 VAC 60/50 ± 3Hz
Power Consumption
58.0W (Maximum)
Power Saving
Less than 2W
Dimensions (WxDxH) / Weight
412.0 x 203.0 x 414.5 mm (when stand is not foleded )
412.0 x 58.5 x 472.0 mm ( when stand is not foled )
412.0 x 58.5 x 407.5 mm / 4.85 kg ( Without stand )
VESA Mounting Interface
100mm x 100mm (for use with Specialty(Arm) Mounting hardware.)
Environmental considerations
Operating Temperature : 50°F ~ 104°F(10°C ~ 40°C)
Humidity : 10% ~ 80%, non-condensing
Storage Temperature : -13°F ~113°F (-25°C ~ 45°C)
Humidity : 5% ~ 95%, non-condensing
SyncMaster 172MP
