ht5000
• Read this manual carefully and keep it in a safe place
for future consultation.
This manual contains important information on how to
install and use this equipment correctly. Before using the
equipment, read the safety prescriptions and instructions
carefully. Keep the manual for future consultation.
• Do not touch internal parts of the units
Inside the cabinet there are electrical parts carrying
dangerously high voltages and parts operating at high
temperature. Never open the cabinet. Entrust all servicing
and repair work to an authorised Service Centre. Opening
the cabinet voids the warranty.
• Disconnecting the appliance from the power supply.
The device which disconnects the unit from the mains is
the power plug. Ensure that the power cable plugs and
the electrical mains socket outlets are easily accessible
during installation operations. Pull the plug, not the cable,
to disconnect the unit from the mains.
• Use only the specified power supply.
1 Projection lens.
2 Magnetic cover for lens sostitution.
3 Remote control IR sensor on front of unit.
4 Unblock lens hole.
5 Adjustable feet.
6 Cooling air inlet/outlet vents.
7 Bulb compartement.
8 Connnection panel.
9 Cooling air inlet/outlet vents.
PROJECTOR
Connect the units to a mains electrical supply with rated
voltage of between 110-240 VAC, 50/60 Hz and equipped
with a protective earth connection. If you are not sure of
your domestic mains rating, contact an electrician. Take
care to avoid overloading the power socket and any ex-
tension leads.
• Changing the fuses.
Before changing the fuse disconnect the unit from the
mains power supply.
The fuse compartment is next to the power supply con-
nector. Remove the fuse holder with a flat head screwdriver
and replace the fuse. Fit a new spare fuse. Use only T 5A
H fuses.
• Be careful with cables.
Make certain cables are routed so that people will not be
impeded or tripped up.
Keep all cables away from children.
Install the unit as close to the wall socket as possible. Avoid
