Specifications
Others
Specifications
Optical characteristics
Projection system
3 LCD panels, 1 lens, 3 primary
color shutter system
LCD panel VPL-FE40: 0.79-inch SXGA+
panel, 4,410,000 pixels (1400 ×
1050 × 3)
VPL-FX40: 0.79-inch XGA panel,
2,359,296 pixels (1024 × 768 ×
3)
Lens 1.3 times zoom lens (powered)
f 30.6 to 39.7 mm/F1.66 to 2.18
* The lens is not supplied with the
VPL-FE40L/FX40L.
Lamp 275 W Ultra high pressure lamp
Projected picture size
40 to 600-inches (measured
diagonally) (When the VPLL-
1008 is used: 60 to 300-inch)
Light output 4000 ANSI lumen
(When the Lamp Mode is set to
“High.”)
Throwing distance for VPL-FE40/FX40 (When
placed on the floor.)
When an SXGA+ (VPL-FE40)/
XGA (VPL-FX40) signal is
input
40-inch: 1.5 to 1.9 m
(4.9 to 6.2 feet)
60-inch: 2.3 to 2.9 m
(7.4 to 9.5 feet)
80-inch: 3.0 to 3.9 m
(9.9 to 12.7 feet)
100-inch: 3.8 to 4.8 m
(12.5 to 15.9 feet)
120-inch: 4.6 to 5.8 m
(15.0 to 19.1 feet)
150-inch: 5.7 to 7.3 m
(18.8 to 23.9 feet)
200-inch: 7.7 to 9.7 m
(25.2 to 32.0 feet)
300-inch: 11.6 to 14.6 m
(37.9 to 48.0 feet)
400-inch: 15.4 to 19.5 m
(50.6 to 64.1 feet)
500-inch: 19.3 to 24.4 m
(63.3 to 80.2 feet)
600-inch: 23.2 to 29.4 m
(76.0 to 96.3 feet)
There may be a slight difference between the
actual value and the design value shown above.
Electrical characteristics
Color system NTSC3.58/PAL/SECAM/
NTSC
4.43/PAL-M/PAL-N/
PAL60 system, switched
automatically/manually
(NTSC
4.43 is the color system used
when playing back a video
recorded in NTSC on a
NTSC
4.43 system VCR.)
Resolution VPL-FE40: 750 horizontal TV
lines (Video input)
1,400 × 1,050 dots (RGB input)
VPL-FX40: 750 horizontal TV
lines (Video input)
1,024 × 768 dots (RGB input)
Acceptable computer signals
1)
fH: 19 to 92 kHz
fV: 48 to 92 Hz
(Maximum input signal resolution:
UXGA 1600 × 1200
fV: 60 Hz)
1)
Set the resolution and the frequency of the
signal of the connected computer within the
range of acceptable preset signals of the
projector.
Applicable video signals
15 k RGB 50/60 Hz, Progressive
component 50/60 Hz, DTV
(480/60i, 575/50i, 480/60p,
575/50p, 720/60p, 720/50p,
1080/60i, 1080/50i, 1080/60p,
1080/50p), Composite video, Y/
C video
Speaker Stereo speaker system, 40 × 70
mm (1
5
/8 × 2
7
/8 inches)
Speaker output
1.8 W × 2
Input/Output
VIDEO IN VIDEO: phono type
Composite video: 1 Vp-p ±2 dB
sync negative (75 ohms
terminated)
S VIDEO: Y/C mini DIN 4-pin
type
Y (luminance): 1 Vp-p ±2 dB
sync negative (75 ohms
terminated)
C (chrominance): burst
0.286 Vp-p ±2 dB (NTSC)
(75 ohms terminated),
burst 0.3 Vp-p ±2 dB (PAL)
(75 ohms terminated)
AUDIO: phono type × 2
rated input 500 mVrms, input
