28-EN
Rated
output level
—
160 mV
Maximum
output level
5 mW +
5 mW
—
Load
impedance
16 ohms
47 kohms
Specifications
General
MIC
LINE IN
Format NT format
Tape Digital micro tape (NT cassette tape)
Recording system Helical scan 2 heads, digital recording
Recording head 4 heads
Recording time 60 minutes (with the supplied NTC-60)
Tape speed Approx. 6.35 mm/s
Drum rotation Approx. 3000 rpm
Error correction Cross-interleaving code
Track pitch Approx. 9.8 µm
Sampling frequency 32 kHz
Modulation system LDM-2
Number of channels 2-channel, stereo
Quantization 12-bit non-linear (equivalent to 17 – bit)
Frequency response 10 Hz to 15,000 Hz (+1, –3dB)
Signal-to-noise ratio More than 80 dB (1 kHz, IHF-A, 20 kHz
LPF, LINE IN)
Dynamic range More than 80 dB (1 kHz, IHF-A, 20 kHz
LPF, LINE IN)
Total harmonic distortion Less than 0.08%
Wow and flutter Below measurable limit (less than 0.001%
W.PEAK)
Input
Jack type
stereo minijack
stereo minijack
Output
Jack
type
stereo
minijack
stereo
minijack
HEADPHONES
LINE OUT
Rated input
level
1.38 mV
160 mV
Minimum
input level
0.55 mV
64 mV
