251
4CIF (704 x 576 pixels), Digital Clarity
Interlaced CIF (352 x 576 pixels), Natural Video
CIF (352 x 288 pixels)
QCIF (176 x 144 pixels)
SQCIF (128 x 96 pixels) decode only
448p (576 x 448 pixels)
NATIVE PC RESOLUTIONS:
XGA (1024 x 768)
SVGA (800 x 600 pixels)
VGA (640 x 480 pixels)
WIDE (16:9) RESOLUTIONS:
w288p (512 x 288 pixels)
w448p (768 x 448 pixels)
w576p (1024 x 576 pixels)
w720p (1280 x 720 pixels)
STILL IMAGE TRANSFER
CIF, SIF, 4CIF (H.261 Annex D), 4SIF, VGA, SVGA,
XGA
AUDIO STANDARDS
G.711, G.722, G.722.1, G.728, MPEG4 AAC-LD
AUDIO FEATURES
CD-Quality 20KHz Mono and Stereo
Telephone add-on via MultiSite
Four separate acoustic echo cancellers
Audio mixer
Automatic Gain Control (AGC)
Automatic Noise Reduction
Audio level meters
VCR ducking
GSM / Blackberry noise filter
AUDIO INPUTS (6 INPUTS)
3 x microphone, 24V phantom powered, XLR connector
1 x RCA / Phono, Line Level: audio mixer
1 x RCA / Phono, Line Level: auxiliary (or VCR/DVD
Stereo L)
1 x RCA / Phono, Line Level: VCR/DVD (Stereo R)
AUDIO OUTPUTS (3 OUTPUTS)
1 x RCA / Phono, S/PDIF (mono/stereo) or
Analogue Line Level: main audio
1 x RCA / Phono, Line Level: auxiliary (or VCR Stereo L)
1 x RCA / Phono, Line Level: VCR (Stereo R)
FRAME RATES – POINT-TO-POINT & MULTISITE
30 frames per second @ 168 kbps and above
60 fields per second @ 336 kbps and above (Point-to-
point)
MULTISITE FEATURES
Audio and Video Transcoding
Video rate matching from 56 kbps – 2 Mbps
Continuos Presence CP5+1, CP4 and Voice Switched
Best Impression
H.264, Encryption, Digital Clarity
DuoVideo and H.239 mixed and from any site
Telephony
ISDN & IP Downspeeding and IPLR
MULTISITE (H.243) CASCADING ON ISDN AND IP
Dial in / Dial out
Chair control for host system
Snapshot of ongoing conference (JPEG)
Snapshot of ongoing DuoVideo/H.239 presentation
(JPEG)
Separate welcome page for encrypted conferences
IP AND PRI/BRI/SERIAL INTERFACE (V.35)
OTHER MAJOR ITU STANDARDS SUPPORTED
H.231, H.233, H.234, H.235, H.235 v2&v3, H.239,
H.241,
H.243, H.281, BONDING (ISO 13871), H.320, H.323,
H.331, MPEG4 AAC-LD (20KHz audio), H.460.18,
H.460.19
W.A.V.E. (WIDE ANGLE VIEW) II CAMERA
10 x zoom 1/4" CCD +15° / -20° tilt
+ / -95°pan
61° vertical field of view
96° total vertical field of view
77° horizontal field of view
267° total horizontal field of view
460 (PAL) / 470 (NTSC) TV lines
Min. illumination 2 Lux (F1.8)
Auto or manual focus / brightness / white balance
Far-end camera control
15 near and far-end camera pre-sets
Voice-activated camera positioning
Daisy chain support for up to 4 cameras VISCA
camera support
PRESENTATIONS AND COLLABORATION
Natural Presenter Package including:
PC Presenter
PC SoftPresenter
Digital Clarity
DuoVideo and H.239
Advanced Video Layouts
Streaming compatible with Cisco IP/TV,
Apple QuickTime®, RealPlayer® v8 etc.
CLOSED CAPTIONING/TEXT CHAT
T.140 standards-based
SYSTEM MANAGEMENT
Support for the TANDBERG Management Suite
Total management via embedded web server, SNMP,
Telnet and FTP
Remote software upload: via webserver or via FTP
server
2 x RS-232 for local software upgrades, local control
and diagnostics
Onscreen Menu on TV and/or VGA monitors
DIRECTORY SERVICES
Support for Local, Global and Dynamic Server
Directories
Unlimited entries using Server directory* supporting
LDAP and H.350
400 number global directory
200 number local directory
50 dedicated MultiSite entries
Last Number Dialed
Missed Calls
Call History
16 SELECTABLE MENU LANGUAGES
English, German, French, Norwegian, Swedish, Italian,
Spanish, Portuguese, Simplified Chinese, Traditional
Chinese, Japanese, Russian, Korean, Finnish, Thai and
Arabic
CUSTOMIZED WELCOME SCREEN AND COMPANY
LOGO
