Troubleshooting
Take Up Reel problems
11-53
Take Up Reel problems
Take Up Reel Does Not function
You may have a power problem. Check the power cable is connected and that
there is power available at the socket.
Check the ON/OFF switch is in the ON position at the back of the Take Up Reel.
Check the Spindle Lever, it should be closed.
Check the sensor cable from the right hand assembly is connected correctly.
Check the sensor operates correctly by placing a sheet of paper over the sensor.
Defective Right Hand Take Up Reel Assembly.
Defective Sensor Assembly.
Media Skewed on Take Up Reel.
Media not loaded straight on the Take Up Core
Media Weight is not the same width as the media being used.
Take Up Core is not the same width as the media being used
Media Weight is not fully inserted.
Take Up spindle is not installed correctly.
Left and Right Hand Take Up Reel Assemblies not installed correctly
Ensure that there are no objects in the Base Tray Assembly
