HP Color LaserJet 3500 custom paper sizes
Note
The PS driver does not support user-defined media sizes.
The following table shows custom paper sizes that are available for the HP Color LaserJet 9500 series printers.
Table 83: HP Color LaserJet 3500 custom paper sizes
Tray
Dimensions Minimum Maximum
Tray 1 Width 98 mm (3.9 inches) 306 mm (12.0 inches)
Height 191 mm (7.5 inches) 469 (18.50 inches)
Tray 2 (500-sheet) Width 148 mm (5.8 inches) 296 mm (11.69 inches)
Height 210 mm (8.2 inches) 432 mm (17.0 inches)
Tray 3 (500-sheet) Width 148 mm (5.8 inches) 297 mm (11.7 inches)
Height 210 mm (8.2 inches) 432 mm (17.0 inches)
Print server operating system migration
The large installed base of printers and print servers in corporate environments, combined with the large user-base for
these printers, implies that an operating system migration takes an extended period of time, often months or even
years, to complete. Because of this, it is unavoidable that the corporate environment ends up operating with a mix of
Windows NT 4.0 and newer operating systems (Windows 2000, Windows XP and Windows Server 2003) for an
extended period of time.
A number of printer driver issues related to operating in a mixed-OS environment must be considered when planning a
print server operating system migration from Windows NT 4.0 to Windows 2000 or later. This section explores these
issues and outlines several strategies that HP recommends to support a mixed OS environment with respect to printer
drivers.
This discussion is not intended to make specific procedural recommendations for executing a print server OS
migration. This discussion is intended to help system administrators and IT managers understand the printer driver
issues related to operating in a mixed-OS environment so that the requirements resulting from the recommendations
outlined in this document can be factored into migration planning.
The topics discussed here apply to IT environments that are currently running Windows NT 4.0 on the print servers
and clients, and are migrating to future operating systems for both print servers and clients. The Windows 9x family of
operating systems is not discussed in this document because Windows 9x clients can be supported with Point and
Print equally well from any server platform. A basic working knowledge of shared printing through Microsoft Windows
Point and Print is assumed.
While much of this discussion is general in nature, all of the specific driver recommendations in this document apply to
HP LaserJet and Business InkJet printers and printer drivers.
Background information and terminology
Version 2 driver
With Windows NT 4.0, printer drivers were considered, generally, to be a class of graphics drivers. Due to the
performance requirements of some types of graphics drivers, like display drivers, these drivers executed in kernel
mode. A kernel mode process runs in a specially privileged part of the operating system that gives the process access
to all of the system resources. Due to the nature of the privileges granted to kernel mode processes, a misbehaving
driver can cause serious system stability problems, including operating system crashes. Microsoft refers to these
kernel mode printer drivers as Version-2 drivers and this is the term used throughout this section.
