Installing the HP JetDirect Print Server Card 2-1
2
Installation
2
Installing the HP JetDirect Print
Server Card
Task 1. If you have a Token Ring card, set
the Data-Rate switch (if necessary)
Before installing a Token Ring card, you must set the data-rate
switch to either 4 Mbit/second or 16 Mbit/second (factory default).
The selected setting depends on the data-rate operation of your
Token Ring network.
1. Locate the Data-Rate switch on the Token Ring print
server card.
2. Set the switch to 4 Mbit/s or 16 Mbit/s.
Note: when switches are pressed toward the Open position,
they are in the 16 Mbit/s setting.
16 Mbit/s
4 Mbit/s positio
n
