Installing the HP JetDirect Print Server Card 2-27
2
Installation
4. Insert the card. Align the card with the guide rails in
the printer.
5. Press the card into the slot until firmly seated and tighten each
thumbscrew a little at a time, alternating between each side
until both screws are secure.
6. Connect the network cable to the card.
7. Connect the power cord.
8. For the HP DeskJet 1200C, 1600C, 1600CM and 1600CN
printers, turn on the power switch.
NOTE
For the HP J4100A JetDirect card (RJ-45 and
BNC), you can connect to
one
of the Ethernet ports
(only one Ethernet port is active at a time).
For the HP J4105A JetDirect card (RJ-45 and DB9),
you can connect to
only one
Token Ring port.
