Icon Main Menu Submenu Description
Key Lock Sets up the monitor so that it can only be used with the remote
control. This feature can prevent unauthorized viewing.
ISM Method Avoids allowing a fixed or burn-in image to remain on the
screen for a long period of time.
Power Indicator Sets the power indicator on the front of the monitor to On or
Off.
DPM (Display
Power
Management)
Select
Turns the power saving mode on or off.
Tile Mode Enlarges the screen and is also used with several products to
view the screen. To use this function, it:
●
must be displayed with several other products.
●
must be in a function that can be connected to RS232C
or RGB Out.
Factory Reset Select this option to return to the default factory settings.
Information Set ID Assigns a unique Set ID number (name assignment) to each
product when several products are connected for display.
Specify the number (1 ~ 99) using the up and down buttons
and exit. Use the assigned Set ID to individually control each
product using the Product Control Program.
Serial No Displays the serial numbers of the product.
SW Version Displays the software version.
Selecting An Aspect Ratio Mode
The aspect ratio modes available for your selection depends on the current input source. Use the
following table to determine which mode is available for your monitor.
ARC \ Mode AV Component HDMI/DVI RGB
DTV PC PC
16:9 XXXXX
Just Scan X X
Original X
4:3 XXXXX
1:1 X X
14:9 X
Zoom1 X
Zoom2 X
28 Chapter 4 Operating the Monitor ENWW
