Table B-2 HP LD4700 Specifications (continued)
Recommended Resolution
RGB
HDMI/DVI
1920 x 1080 @ 60Hz
1920 x 1080 @ 60Hz (if supported by OS or video card type)
Horizontal Frequency
RGB
HDMI/DVI
30 - 83kHz
30 - 83kHz
Vertical Frequency
RGB
HDMI/DVI
56 - 76Hz
56 - 60Hz
Synchronization Type Composite/Separate/Digital
Input Connector 15-pin D-Sub type, HDMI (digital), S-Video, Composite Video,
Component, RS-232C
Environmental Conditions
Operating Temperature
Storage Temperature
0 ~ 35° C, Humidity 10% ~ 80%
-20 ~ 60° C, Humidity 5% ~ 90%
Audio (Select Models)
RMS Audio Output
Input Sensitivity
Speaker Impedance
10W + 10W (R+L)
0.7 rms
8 Ohms
Recognizing Preset Display Resolutions
The display resolutions listed below are the most commonly used modes and are set as factory
defaults. This monitor automatically recognizes these preset modes and they will appear properly
sized and centered on the screen.
HP LD4200 and LD4700 Preset Display Modes
Table B-3 HP LD4200 and LD4700 Factory Preset Display Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 720 x 400 31.468 70.8
*2 640 x 480 31.469 59.94
3 640 x 480 37.5 75
*4 800 x 600 37.879 60.317
5 800 x 600 46.875 75
6 832 x 624 49.725 74.55
*7 1024 x 768 48.363 60
8 1024 x 768 60.123 75.029
ENWW Recognizing Preset Display Resolutions 39
