Remote Control Session via Network Indicator
A yellow exclamation mark in a red
triangle will show up in the lower left
corner just above the help text box when
a Network remote session is in progress.
A remotely connected network session
has priority over local control of the front
panel, so during a Network remote
session the Main Menu will be grayed
out.
Note: No front panel indication is shown
when a serial or modem based remote
control session is in progress!
The triangle with exclamation mark signifies that a TCP/IP Remote Control session is
active. There is no front panel indication shown when a serial or modem based remote
control session is in progress.
Headphone Level Control
A front-panel ¼" stereo headphone jack allows the processed signal to be monitored, and a Headphone
volume level control is available in each submenu. When the headphone volume control slider is
highlighted, clicking changes the jog-wheel into a headphone volume control. Once the headphone volume
is adjusted to your liking, clicking the jog-wheel exits the volume adjustment mode, returning the jog-
wheel back to Highlight Mode.
Note: The headphone amplifiers are fed from the same high quality D to A converter as the analog
outputs. Therefore, the overall Headphone volume will also be affected by the setting of the Peak Output
Level controls in the Output Menu.
