Meters
Feet
Lens Type FWA -1* FWA -2* Short Med-Short Med-Long Long
Ratio**
0.67:1 1.11:1 1.39~1.87:1 1.87~2.56:1 2.56~4.16:1 4.16~6.96:1
1.1 - 3.2 3 -15 4 - 24 4 - 24 9.1 - 45 12 - 80
Throw Distance
(meters)
Image Width Fixed Fixed Min Max Min Max Min Max Min Max
meters
1.5 1 2.1 2.8 2.8 3.8 3.8 6.2 6.2 10.4
3 2 3.4 4.2 5.6 5.6 7.7 7.7 12.5 12.5 20.9
4.5 3 5 6.3 8.4 8.4 11.5 11.5 18.7 18.7 31.3
6 6.7 8.3 11.2 11.2 15.4 15.4 25.0 25.0 41.8
9 10 12.5 16.8 16.8 23.0 23.0 37.4 37.4 62.6
10.5 12 14.6 19.6 19.6 24.0 26.9 43.7 43.7 73.1
13.5 15 18.8 24.0 25.2 34.6 34.6 45.0 56.2 80.0
Throw
Distance
Throw
*FWA – Fixed Wide Angle
** Throw Distance/Image Width
Lens Type FWA -1* FWA -2* Short Med-short Med-long Long
Throw
Ratio**
0.67:1 1.12:1 1.39~1.87:1 1.87~2.56:1 2.56~4.16:1 4.16~6.96:1
Throw Distance (feet)
Image Width Fixed Fixed Min Max Min Max Min Max Min Max
feet
5 3.3 5.6 7 9.4 9.4 12.8 12.8 20.8 20.8 34.8
10 6.7 11.2 13.9 18.7 18.7 25.6 25.6 41.6 41.6 69.6
15 10.0 16.8 20.9 28.1 28.1 38.4 38.4 62.4 62.4 104
20 13.4 22.4 27.8 37.4 37.4 51.2 51.2 83.2 83.2 139
30 20.1 33.6 41.7 56.1 56.1 76.8 76.8 125 125 209
35 23.4 39.2 48.7 65.5 65.5 89.6 89.6 146 146 244
45 30.1 50.4 62.6 84.2 84.2 115 115 187 187 262
(min - max)
3.2 - 9.9 9.9 -49 13.1-78.7 13.1-78.7 29.5 -147 39.3 - 262.3
Distance
Throw
(min - max)
(m)
(ft)
