SMCWHSG14-G
139
1440.
Item Default Description
Device Name Empty The LAN device name. The maximum character of the device name
is 20.
Virtual Port 0 The virtual port number valid range is 60001 to 60050 or 5900 to
5910.
Device IP Address Empty Enter the IP address of LAN device in the format “xxx.xxx.xxx.xxx”
Device Server Port 0 Enter the server port of LAN device.
Device MAC Address Empty The MAC address of LAN device. For input the device MAC
address, please use this format such like”0050BA8D2296”.
Application TCP Select one protocol type of LAN device by clicking in the list box.
Interface Wired Select one interface of LAN device by clicking in the list box.
Click Delete All button to delete all entries.
Click Apply button to save the new settings.
Note: The system does not support FTP.
