SMCWHSG14-G
153
Item Default Description
General Settings
ESSID Wireless
The ESSID is the unique name that is shared among all
points in a wireless network. It is case sensitive and must not
exceed 32 characters.
Channel 6 Select the channel ID for wireless connection.
Security Disable
Select disable to allow wireless station to communicate with
the device without any data encryption. Select enable to
enable WPA or WEP data encryption.
WPA Encryption Wi-Fi Protected Access Encryption
Pre-shared Key Empty
Enter a pre-shared key from 8 to 63 case sensitive ASCII
characters.
Group Key
Re-Keying
86400 Seconds Enter a number in the field to set the force re-keying interval.
Use WPA with
Pre-shared Key
Enable
Pre-Shared Key Empty
Enter a pre-shared key from 8 to 63 case sensitive ASCII
characters.
Use WPA with
RADIUS
Disable
Server IP Empty
Enter the RADIUS server IP address or domain name. The
maximum allowed characters length is 15.
Authentication Port 1812
Enter the authentication port number. The allowed numbers
are from 0 to 65535.
Share Secret Key Empty Enter the RADIUS secret key
WEP Encryption Wired Equivalent Privacy Encryption
Encryption 64 bit
The Wireless Hotspot Gateway supports 64-bit or 128 bit
WEP encryption.
Mode HEX
Options: HEX (Hexadecimal) and ASCII (American Standard
Code for Information Interchange).
