BWS-136 User Manual_amend.doc - 9 -
SW1 Setting:
SW1 Key 1 2 3 4 5
RS-232 ON OFF OFF - -
RS-422 OFF OFF OFF - -
RS-485 OFF ON ON - -
Normal - - - OFF OFF
DHCP OFF ON
Default ON OFF
Console ON ON
Normal: Aport is in Normal Operation Mode
DHCP: Network IP Address is assigned by DHCP Server
Default: All the settings are reset to Factory Default.
Console: COM1 serial port is served as console port. User can
use ACSII command to configure BWS-136 via COM1 port.
Please refer to Appendix I for the ASCII command
Changing the switch settings will not be effective until
system reboot by pressing RESET button
BWS-136 User Manual_amend.doc - 10 -
LED Status
The LED provides the BWS-136 operation information. The
LED status is described as follow:
Power LED: Power LED keeps ON if power (+9VDC to +40VDC)
is correctly input to BWS-136.
Ready LED: Ready LED keeps ON when Aport 211 firmware is
ready for operation. Ready LED will be flash when Aport 211 in
Serial Console mode (SW1 key 4 and key 5 are ON) or Telnet
Console mode (Telnet Console port:5001 are connected)
Link/Act LED: Link and Activity LED will turn ON when the
Ethernet cable is connected. When there is network data traffic,
this LED will be flash.
RX/TX LED: The RX/TX LED is a dual color LED that indicates
the serial data traffic. In RS-232 mode, the Yellow LED stands
for transmitting data and Green LED means receiving data. In
RS-422/485 mode, the Yellow LED stands for receiving data and
Green LED means transmitting data.
