PRODUCT SPECIFICATIONS
LCD panel specifications:
Size/Type 6.8” (diagonal) /TFT LCD
Brightness 250 nit (min)
300 nit (typ.)
Contrast Ratio 60 (min)
150 (typ.)
View Angles
(@ CR?10)
Top (12 o’clock): 25?(min)
Bottom (6 o’clock): 40?(min)
Horizontal: ? 55? (min)
Response Time Rise: 25ms (typ.) ; 50ms (max)
Fall: 30ms (typ.) ; 60ms (max)
Back light Type CCFL
Back light Life 30k hrs (min) ; 40k hrs (typ.)
Operation Temperature Range: -20?C to 65?C
Storage Temperature Range: -40?C to 80?C
Max Humidity: 100? RH
Max Vibration Force: 2.5G
Max Shock Force: 100G
Operating Voltage Range: 10VDC to 16VDC
Current Draw (typical): 50mA (Idle); 1.15A (typ) ; 1.25A (max)
Signal System: NTSC
Video:
? Aspect Ratio: 4:3
? Input format: Composite NTSC
? Input level: 1Vp-p into 75?
Audio
? Input level: -10dBV nominal (317mV)
Product Weight: 2.8lbs (approximate)
Product Overall Dimensions: 7 ¾” (197mm)W x 5 ¼” (134mm)H x 1 3/16” (29.5mm)D
