2-4
Chapter 2: Hardware information
2.2.4 Layout Contents
Slots Page
1. DDR DIMM slots 2-11
2. PCI slots 2-17
3. AGP slot 2-17
Jumpers Page
1. Clear RTC RAM (3-pin CLRTC) 2-18
2. Keyboard power (3-pin KBPWR) 2-19
3. USB device wake-up (3-pin USBPWR12, USBPWR34,
USBPWR56, USBPWR78) 2-19
Rear Panel Connectors Page
1. PS/2 mouse port 2-20
2. Parallel port 2-20
3. IEEE 1394 port 2-20
4. Gigabit LAN port (RJ-45) 2-20
5. Center/Subwoofer jack 2-20
6. Rear Speaker out jack 2-20
7. Line In jack 2-20
8. Line Out jack 2-20
9. Microphone jack 2-20
10. Side Speaker out jack 2-20
11. USB 2.0 ports 3 and 4 2-21
12. USB 2.0 ports 1 and 2 2-21
13. Serial connector 2-21
14. S/PDIF optical cable jack 2-21
15. S/PDIF coaxial cable jack 2-21
16. PS/2 keyboard port 2-21
