viii
B75M-A specications summary
(continued on the next page)
CPU LGA1155 socket for Intel
®
3rd / 2nd Generation Core™ i7 / i5 / i3, Pentium
®
and Celeron
®
processors
Supports Intel
®
22/32nm CPU
Supports Intel
®
Turbo Boost Technology 2.0
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
B75 Express Chipset
Memory 2 x DIMM, max. 16GB, DDR3 2200(O.C.) / 2000(O.C.) /1800 (O.C.) / 1600 /
1333 / 1066 MHz, non-ECC, un-buffered memory
Dual-channel memory architecture
* Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
** When you install a total memory of 4GB capacity or more, Windows
®
32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows
®
32-bit operating
system.
*** Intel
®
3rd generation processors support DDR3 1600 MHz and higher frequency.
Graphics Integrated graphics processor
Multi-VGA output support: HDMI, DVI-D, and D-Sub ports
- Supports HDMI with max.resolution of 1920 x 1200 @60Hz
- Supports DVI-D with max.resolution of 1920 x 1200 @60Hz
- Supports D-Sub with max. resolution of 2048 x 1536 @75Hz
Maximum shared memory of 1 GB
Expansion slots 1 x PCI Express 3.0/2.0 x16 slot
2 x PCI Express 2.0 x1 slots
1 x PCI slot
Storage Intel
®
B75 Express Chipset:
- 5 x Serial ATA 3.0 Gb/s connectors (blue)
- 1 x Serial ATA 6.0 Gb/s connector (gray)
LAN
Realtek
®
8111F-VB-CG Gigabit LAN controller
Audio 6+2 Channels Realtek
®
ALC887-VD High Denition Audio CODEC
- Supports jack-detection, multi-streaming, anti-pop function, and front
panel jack-retasking
* Use a chassis with HD audio module in the front panel to support an 8-channel
audio output.
USB 4 x USB 3.0 ports (2 ports at midboard, 2 ports at back panel)
8 x USB 2.0 ports (4 ports at midboard, 4 ports at back panel)
