ASUS K8V-F motherboard user guide
2-13
HyperTransport Configuration
HyperTransport Configuration
HT Tristate Enable [Disabled]
CRC Flood Enable [Disabled]
HT Frequency [800MHz]
HT DATA Width (Upstream) [16 BIT]
HT DATA Width (Downstream) [16 BIT]
Enable link tristate
during the disconnected
state of an LDTSTOP.
HT Tristate Enable [Disabled]
This item enables or disables the HyperTransport Tristate that allows tristate link
during the disconnected state of an LDTSTOP.
Configuration options: [Disabled] [Enabled]
CRC Flood Enable [Disabled]
This item enables or disables the CRC Flood that allows synchronized packet
generation on CRC Error. Configuration options: [Disabled] [Enabled]
HT Frequency [800 MHz]
This item allows you to select the frequency of HyperTransport transfer from K8
CPU to AGP. Configuration options: [200 MHz] [400 Mhz] [600 Mhz] [800 Mhz]
HT DATA Width (Upstream) [16 BIT]
This item allows selection of the HyperTransport upstream data width.
Configuration options: [16 BIT] [8 BIT]
HT DATA Width (Downstream) [16 BIT]
This item allows selection of the HyperTransport downstream data width.
Configuration options: [16 BIT] [8 BIT]
HyperTransport Configuration
HT Tristate Enable [Disabled]
CRC Flood Enable [Disabled]
HT Frequency [800MHz]
HT DATA Width (Upstream) [16 BIT]
HT DATA Width (Downstream) [16 BIT]
Enable link tristate
during the disconnected
state of an LDTSTOP.
