ASUS M2NBP-VM CSM 2-33
2.5.4 Hardware Monitor
The items in this sub-menu displays the hardware monitor values automatically
detected by the BIOS. It also allows you to change CPU Q-Fan feature-related
parameters. Select an item then press <Enter> to display the conguration options.
Q-Fan Controller [Disabled]
Allows you to enable or disable the Q-Fan controller.
Conguration options: [Disabled] [Enabled]
Vcore Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage
The onboard hardware monitor automatically detects the voltage output through
the onboard voltage regulators.
Conguration options: [xxx] [Ignored]
CPU Temperature, M/B Temperature
The onboard hardware monitor automatically detects and displays the motherboard
and CPU temperatures. These items are not user-congurable.
CPU Fan Speed [xxxxRPM]
Chassis Fan1/Fan2 Speed [xxxxRPM]
Power Fan Speed [xxxxRPM]
The onboard hardware monitor automatically detects and displays the CPU,
Chassis, and chip fan speeds in rotations per minute (RPM). If any of the fans is
not connected to the motherboard, the eld shows 0. These items are not user-
congurable.
CPU Fan Speed warning [800 RPM]
Sets the CPU fan speed warning feature.
Conguration options: [Disabled] [800RPM] [1200RPM] [1600RPM]
Select Menu
Item Specic Help
Press [Enter] to
enable or disable
Hardware Monitor
Q-Fan Controller [Disabled]
Vcore Voltage [ 1.41V]
3.3V Voltage [ 3.28V]
5V Voltage [ 4.98V]
12V Voltage [ 11.58V]
CPU Temperature 35ºC
M/B Temperature 34ºC
CPU Fan Speed 3068 RPM
Chassis Fan1 Speed 0 RPM
Chassis Fan2 Speed 0 RPM
Power Fan Speed 0 RPM
CPU Fan Speed warning [ 800 RPM]
Phoenix-Award BIOS CMOS Setup Utility
Power
