Internal Connectors
1 x USB 3.0 connector supports additional 2 USB 3.0 ports
2 x USB 2.0 connectors support additional 4 USB 2.0 ports (1
connector shares with ROG_EXT header)
1 x ROG Extension (ROG_EXT) header
10 x SATA 6Gb/s connectors
1 x 4-pin CPU fan connector
1 x 4-pin CPU optional fan connector
3 x 4-pin Chassis fan connectors
3 x 4-pin Optional fan connectors
3 x Thermal sensor connectors
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V Power connector
1 x 4-pin EATX 12V Power connector
10 x ProbeIt Measurement Points
1 x Power-on button
1 x Reset button
1 x MemOK! button
1 x DirectKey button
1 x DRCT (DirectKey) header
1 x S/PDIF out header
1 x Front panel audio connector (AAFP)
1 x System panel connector
1 x TPM connector
1 x mPCIe Combo II connector
1 x FastBoot switch
BIOS Features
64 Mb UEFI AMI BIOS, PnP, DMI 2.0, WfM 2.0, SM BIOS 2.5, ACPI
2.0a, Multi-language BIOS
Manageability WfM2.0, DMI2.0, WOL by PME, PXE
Software
Drivers
ROG GameFirst II
ROG RAMDisk
ROG CPU-Z
ROG Mem TweakIt
Kaspersky
®
Anti-Virus
DAEMON Tools Pro Standard
ASUS WebStorage
ASUS Utilities
Form Factor ATX Form Factor, 12” x 9.6” (30.5cm x 24.4cm)
Specications are subject to change without notice.
