1-4
Chapter 1: Product introduction
1.4 Motherboard overview
Before you install the P4B533-VM motherboard, familiarize yourself with
its physical configuration and available features to facilitate the
motherboard installation and future upgrades. A sufficient knowledge of the
motherboard specifications will also help you avoid mistakes that may
damage the board and its components.
1.4.1 Major components
The following are the major components of the P4B533-VM motherboard
as pointed out in the picture on page 1-5.
See page 1-6 for the specifications of each component. Refer to
Chapter 2 for detailed information on the components.
1. DIP switches
2. ATX 12V connector
3. CPU socket
4. North Bridge controller
5. DDR DIMM sockets
6. ATX power connector
7. Super I/O controller
8. Floppy connector
9. IDE connectors
10. Flash EEPROM
11. South Bridge controller
12. ASUS ASIC
13. AGP slot
14. Standby power LED
15. Audio CODEC (optional)
16. PCI slots
17. AGP warning LED
18. LAN PHY (optional)
19. PS/2 mouse port
20. Parallel port
21. RJ-45 port (optional)
22. Line In jack (optional)
23. Line Out jack (optional)
24. Microphone jack (optional)
25. USB 2.0 ports 1 and 2
26. Video port
27. Serial port
28. USB 2.0 ports 3 and 4
29. Keyboard port
