2-24 Chapter 2: BIOS setup
2.4.4 Onboard Device s Confi guratio n
Congure Win627DHG Super IO Chipset
HD Audio Controller [Enabled]
Front Panel Support Type [AC97]
Onboard PCIEX 10/100Mb LAN [Enabled]
LAN Option ROM [Disabled]
Serial Port1 Address [3F8/IRQ4]
Parallel Port Address [378]
Parallel Port Mode [ECP]
ECP Mode DMA Channel [DMA3]
Parallel Port IRQ [IRQ7]
Slot Power [Auto]
Sets the slot power. Conguration options: [Auto] [Light] [Normal]
[Heavy] [Heavier]
High Priority Port Select [Disabled]
Selects the high priority port. Conguration options: [Disabled]
[PCI Express Port 2]
HD Audio Controller [Enabled]
Enables or disables the Azalia/AC’97 CODEC.
Conguration options: [Enabled] [Disabled]
Front Panel Support Type [AC97]
Allows you to set the front panel audio connector (AAFP) mode to
legacy AC’97 or high-denition audio depending on the audio standard
that the front panel audio module supports. Conguration options:
[AC97][HD Audio]
Onboard PCIEX 10/100Mb LAN [Enabled]
Allows you to enable or disable the onboard PCIEX 10/100Mb LAN
controller. Conguration options: [Enabled] [Disabled]
LAN Option ROM [Disabled]
Allows you to enable or disable the option ROM in the onboard LAN
controller. This item appears only when the Onboard LAN item is set
to Enabled. Conguration options: [Disabled] [Enabled]
