ASUS P5LD2-VM DHASUS P5LD2-VM DH
ASUS P5LD2-VM DHASUS P5LD2-VM DH
ASUS P5LD2-VM DH
1-31-3
1-31-3
1-3
IntelIntel
IntelIntel
Intel
®®
®®
®
945G chipset 945G chipset
945G chipset 945G chipset
945G chipset
The Intel
®
945G graphics memory controller hub (GMCH) and the ICH7 DH
I/O controller hub provide the vital interfaces for the motherboard. The
GMCH features the Intel
®
Graphics Media Accelerator 950, an integrated
graphics engine for enhanced 3D, 2D, and video capabilities. The GMCH
provides the interface for a processor in the 775-land package with 533/
800/1066 MHz front side bus (FSB), dual channel DDR2 at speeds of up to
667 MHz, and PCI Express x16 graphics card.
The Intel
®
ICH7 DH Southbridge represents the seventh generation I/O
controller hub that provides the interface for PCI Express and 8-channel
high definition audio.
IntelIntel
IntelIntel
Intel
®
Viiv™ Technology support Viiv™ Technology support
Viiv™ Technology support Viiv™ Technology support
Viiv™ Technology support
Intel
®®
®®
®
Viiv™ Technology transforms your PC into an entertainment center,
allowing you to enjoy and share digital multi-media content like never
before. With Intel
®®
®®
®
Viiv™ Technology-based computers, you can record,
playback, organize, and edit digital media content easily. Enjoy the
entertainment experience even more with sharp graphics, flawless video
playback, and support for up to 7.1 channel surround sound. To enable
Intel
®®
®®
®
Viiv™ Technology, make sure you enable the Quick Resume function
called
Energy LakeEnergy Lake
Energy LakeEnergy Lake
Energy Lake in the BIOS. Refer to the BIOS screen on page 2-33.
You also need to install the Intel
®®
®®
®
Viiv™ Technology driver and software.
See pages 3-4 and 3-5 for details.
Enabling Intel Viiv platform also requires:
- Intel
®
Pentium
®
D processor or Intel
®
Pentium
®
processor
Extreme Edition
- Native Command Queuing (NCQ) SATA hard drive
- Microsoft Windows XP Media Center Edition Update Rollup 2
Refer to www.Intel.com for more information.
DDR2 memory supportDDR2 memory support
DDR2 memory supportDDR2 memory support
DDR2 memory support
The motherboard supports DDR2 memory which features data transfer rates
of 600 MHz (FSB 800) or 533 MHz (FSB 1066/800) to meet the higher
bandwidth requirements of the latest 3D graphics, multimedia, and Internet
applications. The dual-channel DDR2 architecture doubles the bandwidth of
your system memory to boost system performance, eliminating bottlenecks
with peak bandwidths of up to 8.5 GB/s. See pages 1-16 to 1-18 for details.
Dual-core processors contain two physical CPU cores with dedicated L2
caches to meet demands for more powerful processing. Intel(R)’s 65nm
process is the most advanced chip manufacturing technology,
delivering breakthrough performance, enhanced media experience, and low
power consumption. Intel(R) 65nm dual-core processors utilize the latest
package technologies for a thinner, lighter design without compromising
performance.
