Barco 4MP/6MP Projector User Manual



10 Coronis Fusion 4MP/6MP
CORONIS FUSION 4MP
+24 VDC power input USB upstream connector
USB downstream connector +5 VDC, 0.25 A power output
for accessories
+3.3 VDC, 0.25A auxiliary
power output
DVI 1 video input
DVI 2 video input
6
1
2
3
4
5
7
1 2
3 4
5 6
7
