Installation
Before You Begin:
1. Make sure that all computers are powered off and that each PRO2 has
been assigned a unique BANK address.
2. Place Master and Slave switches in the desired location. Make sure all
are turned off and unplugged from the power source.
3. Connect the Console monitor, keyboard, and mouse to the Console
ports of the Master switch or Bank 00, as described previously in this
installation guide.
Connecting the Master Switch to the First Slave Switch:
4. Using the daisy-chain cable (F1D108-CBL), connect one end of the cable
to the “Master Input/Slave Output” port on the Master switch (BANK 00).
5. Connect the other end of the daisy-chain cable to the “Master Input/Slave
Output” port of the first Slave switch (BANK 01).
Adding Additional Slave Units:
6. Using the daisy-chain cable (F1D108-CBL), connect one end of the cable
to the available daisy-chain port labeled “Slave Input” on the Slave switch
(for example, BANK 01).
7. Connect the other end of the daisy-chain cable to the “Master Input/Slave
Output” port of the Slave switch that you are adding
(for example, BANK 02).
8. Repeat steps 6 and 7 for additional PRO2s you wish to
daisy-chain together.
