Selecting a Computer Using Keyboard Hot Key Commands:
Switch to the next or previous port with simple keyboard key sequences
using the “Scroll Lock” key and either the up or down arrow keys. To send
commands to the PRO2, the “Scroll Lock” key must be pressed twice within
two seconds. The PRO2 will beep, confirming that it is in hot key mode.
Next, press the up or down arrow keys, and the PRO2 will switch to either
the prior port or the next port.
With a single-switch configuration (no daisy-chained switches), you can
switch directly to any port by entering the two-digit number of the port you
wish to access. For example, if you press “Scroll Lock”, “Scroll Lock”, “02”,
the PRO2 will switch to the computer on port 2 located on BANK 00.
Note: You will have approximately five seconds to complete each
hot key sequence.
With daisy-chain switch configuration, you can switch between BANKs by
pressing “Scroll Lock”, “Scroll Lock”, “Page Up”, to switch to the previous BANK.
Press “Scroll Lock”, “Scroll Lock”, “Page Down”, to switch to the next BANK.
USING YOUR PRO2
Page
Up
Switch to BANK 00, Port 2—(02)
+
Page
Down
+
++ ++
Switch to previous BANK—Page Up
Switch to next BANK— Page Down
++
Switch to next active port—Down arrow
Switch to previous active port—Up arrow
++
