REF.NO. CODE Q'TY DESCRIPTION REMARKS
1 PLATEN FRAME ATTACHMENT
2 UF9650001 1 DRIVE UNIT
3 Z25947001 1 MOTOR
4 U09759001 1 SCREW, PAN (WASHER) M3X6 DB
5 UF9693001 1 SEPARATION ROLLER GEAR
6 UF6613001 1 SEPARATION ROLLER
7 UU0244001 1 LF ROLLER ASSY
8 UF9949001 1 BEARING, EJECTION ROLLER
9 UG6602001 1 MOTOR HARNESS
10 UG6683001 1 CIS UNIT
11 UF9814001 1 CIS HOLDER, R
12 UF9815001 1 CIS HOLDER, L
13 UF9816001 1 CIS FILM
14 085310815 2 TAPTITE, BIND B M3X8
15 UU0231001 1 TAPTITE, PAN B M3X8
16 UG5013001 1 CIS-MAIN HARNESS
17 LE0830001 1 RECORDER FRAME
18 087310815 2 TAPTITE, CUP B M3X8
19 UF9852001 1 RECORDING HEAD ASSY
20 UF8072001 3 HEAD SPRING, COMPRESSION
21 UG6606001 1 MAIN-HEAD HARNESS FOR FAX-910/920/921/MFC-925
21 UG6707001 1 MAIN-HEAD HARNESS FOR FAX-930/931/940/MFC-970MC
22 UG6607001 1 HEAD-POWER HARNESS
23 UF9855001 1 HEAD ADJUSTER
24 UF9856001 1 HEAD PROTECTOR
25 UF9857001 1 GROUNDING SPRING
26 UF9800001 1 MAIN FRAME, GRAY(1395), FAX-910/920/930/940
FOR GER/UK/FRA/NOR/CHE/IRE/FIN/DEN/AUS/ISR/SWE/CZE/GNR
26 UF9800002 1 MAIN FRAME, WHITE(1397), FAX-920/FAX-930 FOR ARL/NZ
26 UF9800003 1 MAIN FRAME, WHITE(1138),
FAX-920 FOR UK, FAX-921/FAX-931/MFC-925/MFC-970MC
27 UG6670001 1 SPEAKER
28 UG6698001 1 PC I/F MODULAR HARNESS
29 UF9801001 1 HANDSET MOUNT, GRAY(1395), FAX-920/930/940
FOR GER/UK/FRA/NOR/CHE/IRE/FIN/DEN/AUS/ISR/SWE/CZE/GNR
29 UF9801002 1 HANDSET MOUNT, WHITE(1397), MFC-920/930 FOR ARL/NZ
29 UF9801003 1 HANDSET MOUNT, WHITE(1138), FAX-921/931/MFC-925/970MC,
FAX-920 FOR UK
29 UF9983001 1 DUMMY MOUNT, GRAY(1395) FOR FAX-910
30 UG6615001 1 HOOK SWITCH PCB FOR FAX-920/921/930/931/940
/MFC-925/970MC
31 UF9802001 1 DOCUMENT REAR SENSOR ACTUATOR
32 UF9803001 1 COVER SENSOR ACTUATOR A
33 UF9817001 1 COVER SENSOR ACTUATOR B
34 UF9818001 1 COVER SENSOR ACTUATOR SPRING
35 UF9804001 1 RIBBON SENSOR ACTUATOR
36 UF9806001 2 PANEL-LOCK LEAF SPRING
37 UU0021001 1 PINCH ROLLER
38 UF6267000 1 ROLLER SHAFT
39 UF9807001 2 PINCH ROLLER SPRING
40 UL6244002 2 DOCUMENT PRESSURE ROLLER
41 UF6267000 1 ROLLER SHAFT
42 UF9808001 1 DOCUMENT PRESSURE ROLLER SPRING
43 UU0074001 1 LF LEAF SPRING
FAX-910,FAX-920,FAX-921,FAX-930,FAX-931,FAX-940,MFC-925,MFC-970MC/Ver.P
