Brother 2600, 2610 Printer User Manual



7
In order to provide even more illustration and layout features to the label-making possibilities
available with your P-touch 2600/2610, two applications are available on the enclosed CD-
ROM: P-touch Editor 3.2 and P-touch Quick Editor. With either application, the printer driver
must also be installed in order to print labels from the P-touch 2600/2610.
On an IBM PC-Compatible Computer
BEFORE INSTALLATION
Check that your system configuration meets the following requirements.
Computer: IBM PC or compatible
Operating system: Pre-installed with Microsoft
®
Windows
®
98, 98 SE, Me, 2000 Professional
or XP
For installation on Windows
®
2000, administrator privileges are required. In addition,
printing requires power user or administrator privileges. This software cannot be oper-
ated in Users groups. In addition, this software is not compatible with the Windows
®
2000 Server operating system.
With Windows
®
XP, printing and installation is only possible from an account with
administrator privileges. These operations cannot be performed from an account with
limited privileges.
Hard disk free space: At least 20 MB (100 MB to install full option)
Up to 100 MB of hard disk free space may be needed when printing long labels or large
amounts of data.
Memory: At least 64 MB
Monitor: VGA or higher graphics card
USB port
CD-ROM drive
INSTALLING THE P-TOUCH EDITOR 3.2 SOFTWARE
The P-touch Editor 3.2 software includes a variety of more complex functions for printing bar-
codes and images, enabling you to design just about any label that you can image. Install the
P-touch Editor 3.2 software onto a PC as described below.
Do not connect the P-touch 2600/2610 to the computer before installing the software,
otherwise it may not be installed correctly. Be sure to connect the P-touch 2600/2610
only when you are instructed to do so.
INSTALLING THE SOFTWARE AND PRINTER DRIVER
