Catalyst 3560-C and 2960-C Switch Hardware Installation Guide
OL-23803-02
Chapter 1 Product Overview
Front Panel
Front Panel
• 8 or 12 downlink Ethernet ports of one of these types:
–
10/100
–
10/100/1000
–
10/100 PoE
–
10/100 PoE+
–
10/100/1000 PoE
–
10/100/1000 PoE+
• Two 10/100/1000 uplink ports or two dual purpose ports
• RJ-45 console port
• USB mini-Type B (console) port
• USB Type A port (available on the Catalyst 3560CPD-8PT-S, 2960CG-8TC-L, 3560CG-8PC-S, and
3560CG-8TC-S switches)
• LEDs
All the 8-port and 12-port switches have similar components. See Figure 1-1, Figure 1-2, Figure 1-3,
Figure 1-4, and Figure 1-5 for examples.
Catalyst 3560C-8PC-S 8 10/100 PoE+ ports and 2 dual-purpose ports.
Catalyst 3560C-12PC-S 12 10/100 PoE+ ports and 2 dual-purpose ports.
1. PoE = Power over Ethernet
2. SFP = small form-factor pluggable
Table 1-1 Switch Model Descriptions (continued)
Switch Model Description
