— 27 —
1. Entering memory switch setting mode.
Set paper in the printer and keep the printer cover open. With the FEED button
pressed and held, turn the printer power on, and then press the FEED button twice.
Close the cover. If the current settings of the memory switch etc. are printed, the
printer is now in the memory switch setting mode.
2. Selecting memory switch (MEMORY SWITCH SELECT MODE)
When the FEED button is pressed short (*1), printing occurs in the order of “Memory
SW1” → “Memory SW2” → “Memory SW3” → ......“Memory SW10” → “Save To
Memory” → “Memory SW1” → ...... repeatedly. When the memory switch you
want to change is reached, press and hold the FEED button (for more than 2 seconds).
3. Selecting each switch item
2-16 items are provided for setting in each switch. By pressing and holding the
FEED button long (*2), the printer goes to the next item and prints the current setting
of the item. Repeat pressing and holding untill the item you want to change is
reached.
4. Changing the setting
When the item you want to change is printed, press the FEED button short (*1).
The changed set value is printed. (When the change of the set value is repeated,
the original set value is recovered). When you press the FEED button long (*2), the
set value is accepted and then the printer goes to the next setting item.
5. Returning to the MEMORY SWITCH SELECT MODE (the above Item 2)
When the setting of the desired content is completed, open the printer cover and
then close the printer cover. This allows the printer to print the setting of the changed
memory switch.
6. Saving the setting and exiting the memory switch setting mode
Press the FEED button short (*1) to move to “Save To Memory”. Then press and
hold the FEED button. The printer prints the contents of new setting and exits the
memory switch setting mode to return to the normal standby state.
* Unless saving the setting is executed, the changed setting cannot be
enabled.
7. Initializing the memory switch
When you want to return the memory switch setting to the initial state, go to “Save
To Memory” in the above procedure. Here, open the printer cover and press and
hold the FEED button till buzzer sounds. This allows the printer to return to the
initial state.
* All the memory switches settings are returned to the factory set values.
*1: Press for less than 2 seconds *2: Press for more than 2 seconds
Power ON Info (Valid )
OFF state: ERROR LED OFF
ON state: ERROR LED ON
(With memory switch SW7 through SW10, ERROR LED goes on only at the factory setting.)
Memory SW (1) 00000000
0: OFF state
1: ON state
(No indication for 0/1 with memory switch SW7 through SW10)
