6-2
6.1 Main Specifications
Item Description
Printing ･ Direct-thermal or thermal-transfer printing
･ 400 dpi (16 dots/mm) print head
(Main scanning line density: 15.75 dots/mm)
(Subscanning line density: 16 lines/mm)
･ Max. print width: 4.2 in (105.7 mm)
･ Max. paper width: 4.65 in (118 mm)
･ Max. print length: 10 in (254 mm)
Print speed ･ 2, 3, and 4 inches/seconds
Print mode ･ Batch mode: Performs normal printing (single or multi sheets)
･ Peel mode: Prints and peels label from liner
･ Cut mode: Prints and cuts by the specified number of sheets
(label back-feed enabled)
･ Tear-off mode: Presents paper to tear-bar and feeds back to the
print starting position
Bar code generator One-dimensional bar code:
･ Code 3 of 9 ･ POSTNET
･ Interleaved 2 of 5 ･ UCC/EAN128
･ UCC/EAN ･ Telepen
･ Code 128 ･ EAN-13 (JAN-13)
･ Codabar (NW-7) ･ HIBC (Modulus 43-used code 3 of 5)
･ EAN-8 (JAN-8) ･ Int 2 of 5 (Modulus 10-used Inter
leaved 2 of 5)
･ UPC-A ･ UPC-E
･ Plessey ･ CASE CODE
･ Code 93 ･ UPC2DIG ADD
･ UPC5DIG ADD
Two-dimensional bar code:
･ UPS Maxi Code ･ PDF-417
