6-16
･ Paper is fed to the cut position
･ When manual tearing is needed, tear the label at this time.
･ Performs next label printing.
When next print data is transmitted from the computer, the printer feeds back
paper to the previous print completed position and resumes printing.
6.5.3 Tear-off when feeding
･ The paper is fed to the tear position.
･ When the manual tearing is needed, tear the label at this time.
･ Performs the next feeding or label printing.
If the Feed key is pressed or next print data is transmitted from the computer,
the printer feeds back paper to the previous print completed position and
resumes feeding or printing.
Tear-off will start if no data is sent
for 0.5 second after printing
Paper is fed to the position where
manual cutting is possible
Paper is fed back to the previous
print completed position and
printing resumes
Peeling (manual tearing)
Platen
Paper position sensor
Print head
