7
INSTALLATION (Continued)
Connecting the monitor
Front Cover
Screen
Power Switch
Tilt & Swivel
Base
Front View
Rear Cover
AC Inlet
Power Cord
Signal Input
Rear View
to a
p
ower outlet to the host
of the correct volta
g
e Si
g
nal Cable com
p
uter
1. Installation
Install the monitor in an suitable environment.
Do not place the monitor on an unstable base.
Do not expose the monitor to rain, moisture, dust, corrosive gases, vibrations, etc.
so as to prevent electrical shock or fire hazard.
Avoid placing the monitor in direct sunlight or near heating appliances.
2. Signal Cable Connection
(1) Use video signal cable which is included in the carton box.
(2) Insert the connector of a signal cable to the Signal Input Connector of the monitor,
with attention to the suitability, and secure the screws on the connector shell firmly.
(3)Connect the other connector end of the signal cable to the host computer
3. Power Cord Connection
(1) Make sure to use the power cord meeting the safety standard of the country in which
you are using the monitor.
(2) Insert the connector of a power cord to the AC Inlet of the monitor.
(3) Insert the plug of the power cord to a power outlet of the correct voltage.
Before inserting the plug of the power cord into a power outlet of the correct voltage,
check that the connection portion of the power cord is clean (with no dust). Then,
insert the plug of power cord into a power outlet firmly to avoid electrical shock or
fire hazard.
