12. Technical Specifications
MP Nova4 DT & TT
Dimensions (H x W x L)
DT: 150 x 232 x 360 mm (6” x 9⅛” x 14⅛”)
TT: 210 x 250 x 360 mm (8¼” x 9½” x 14⅛”)
Weight DT: 5.8 kg (12 lbs), TT: 7.2 kg (15 lbs)
Power pack 100/240V AC 50-60 Hz, 325 VA
Printer technology Direct thermal and thermal transfer
Printing width 104 mm (4⅛”)
Printing speed DT: 80 – 250 mm/second, TT: 80 – 250 mm/second
Printing resolution 200 dpi / 300 dpi
Media specifications
Width: 40 mm – 115 mm (1½” – 4½”)
Length: 10 mm (⅜”) – unlimited
Thickness: 58 μm – 180 μm
Media types
Roll or fan-folded paper
External diameter of roll: max 215 mm (8½”)
Inner core of roll: min 37 mm (1½”) in diameter
Ink ribbon, TT
Max width of roll: 110 mm (4⅓”)
Inner core diameter of roll: 25 mm (1”)
Max length: 300 m (328 yards)
Connections
2 x RS232 ports (up to 115 kBps)
USB-port
Ethernet port (TCP/IP [LPD, R Telnet])
Typefaces
10 scalable typefaces
13 scalable, emulated typefaces
Supports true type typefaces
Barcodes
Most common barcodes including two-dimensional.
Examples: EAN128, Interleaved 2 of 5, Code 39 and PDF417
Graphics Supports several file types
Settings program Internal program using web browser, Telnet or hyperterminal
Counters 10 internal counters
Memory 2 Mb standard RAM
Time and date Internal clock, real-time
Print head diagnostic PHD (Print Head Diagnostic)
