DSL-200 ADSL USB Modem User’s Guide
8
3
4 S
OFTWARE
I
NSTALLATION
The DSL-200 can be used with the following operating systems:
♦ Microsoft Windows 98
♦ Microsoft Windows 98 Second Edition
♦ Microsoft Windows 2000
The procedures for each system are slightly different so be sure to follow the
instructions provided for your PC’s operating system.
The Microsoft Plug and Play feature will automatically detect the modem after it has
been installed. A new window will appear for each step of the installation.
If you wish uninstall the Modem see Appendix B for instructions.
What Driver to Install
You will need to select one driver to operate the Modem. Which driver you use will
depend on the particular protocol used to provide your ADSL service. Ask your
telephone company or ISP to assist you in selecting either the WAN or LAN driver to
operate the Modem. Only one driver should be installed.
Specifically, if your ADSL service uses the protocol defined by RFC 2364, PPP over
ATM Adaptation Layer 5, then you will need to install the WAN driver. If the protocol
used for your ADSL service is defined by RFC 1483, Muliprotocol Encapsulation over
ATM Adaptation Layer 5, then you will need to install the LAN driver.
