IP258
31
FULL MENU STRUCTURE - LOCATION OF PARAMETERS
MAIN MENU SUB MENU 1 SUB MENU 2 PARAMETER DESCRIPTION Par No.
TOGGLE RUN Toggle
CALIBRATION AUTOCAL SET ZERO L125
(specific) SET SPAN L126
LAB VALUES L127
Max % solids
MANUAL ENTRY SENSOR Sensor Gap P100
Sludge Type P101
dB Factor @ 1MHz P102
dB Factor @ 3MHz P103
ZERO REF Zero Ref @ 1MHz P120
Zero Ref @ 3.3MHz P121
Date of Zero Ref P122
Initial Zero Ref @ 1MHz P123
Initial Zero Ref @ 3.3MHz P124
SPAN Span 1 @ 1MHz P130
Span 1 @ 3.3MHz P131
Span 2 @ 1MHz P132
Span 2 @ 3.3MHz P133
Span 3 @ 1MHz P134
Span 3 @ 3.3MHz P135
Date for Span 1 P140
Date for Span 2 P141
Date for Span 3 P142
LAB VALUES Lab Value 1 P150
Lab Value 2 P151
Lab Value 3 P152
Max % Solids P160
SETUP DUTY (Mode) PV Calculation PV Units P200
Density Units P201
Description P240
Message P241
Tag P242
DESLUDGE Start On P250
Stop On P251
Do not Start if P252
Stop If P253
Start Time #1 P254
Interval #1 P255
Start Time #2 P256
Interval #2 P257
INPUT SENSOR INPUT Serial Number 1 P300
Type 1 P301
Damping 1 P302
OUTPUT CURRENT Lower range value P400
OUTPUT Upper range value P401
Alarm action P402
0-20mA/4-20mA P403
RELAY Relay 1 mode
P410
Relay 1 On Point
P411
Relay 1 Off Point P412
Relay 1 Min On Time P413
Relay 1 Max On Time P414
RL 1 Min Off Time P415
Relay 2 mode P420
Relay 2 On Point P421
Relay 2 Off Point P422
Relay 2 Min On Time P423
Relay 2 Max On Time P424
RL 2 Min Off Time P425
APPENDIX A1
