FS-8704-12_GE-EGD Manual Page 8 of 26
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com
4.4. Client Side Map Descriptors
4.4.1. FieldServer Specific Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name
Name of this Map
Descriptor
Up to 32 alphanumeric characters.
The Map Descriptor name can be any
name that has meaning to you and
need not be unique.
This driver recognizes a special Map
Descriptor name; "EGD-ii". It stands for
EGD Internal Indications. Its use is
more fully explained in Appendix B.1 of
this manual.
Data_Array_Name
Name of Data Array
where data is to be
stored in the
FieldServer
One of the Data Array names from
“Data Array” section above
Data_Array_Location
Starting location in
Data Array
0 to maximum specified in “Data Array”
section above
Function
Function of Client
Map Descriptor
Passive
4.4.2. Driver Specific Map Descriptor Parameters
Column Title Function Legal Values
Node_Name Name of Node to fetch data from
One of the node
names specified in
“Client Node
Descriptor” above
Length
Number of points being consumed for Bit
values this represents the number of bytes
(i.e. number of points divided by 8)
1 - 1000
