4.3.2 SCA2 type SCSI model (MAA31xxSC, MAB30xxSC, MAC30xxSC)
(1) Connectors
Figure 4.24 shows the locations of connectors and terminals on the SCA2 type SCSI model.
SCSI connector (including power supply connector)
Figure 4.24 Connectors and terminals location of SCA2 type SCSI model
SCSI connector
