Table 4.14 MODE SELECT EXTENDED command (group 2)
parameter configuration (1/2)
Header
Bit
Byte
7 6 5 4 3 2 1 0
0 X'00'
1 X'00'
2 X'00' (Medium Type)
3 × 0 0 × 0 0 0 0
4 X'00'
5 X'00'
6 X '00' (Block Descriptor Length: MSB)
7 X'00' or X'08' (Block Descriptor Length: LSB)
Block Descriptor
Bit
Byte
7 6 5 4 3 2 1 0
0 Data Block Count (MSB)
1 Data Block Count
2 Data Block Count
3 Data Block Count (LSB)
4 X'00'
5 Data Block Length (MSB)
6 Data Block Length
7 Data Block Length (LSB)
Page Descriptor
Bit
Byte
7 6 5 4 3 2 1 0
0 0 0 Page Code
1 Page Length
2
n
~
~
~
~
~
~
Page
Heade
r
Parameter Field
