5.3 Host Commands
C141-E042-01EN 5-29
At command issuance (I/O registers setting contents)
1F7
H
(CM) 0001xxxx
1F6
H
(DH)
×××
DV xx
1F5
H
(CH)
1F4
H
(CL)
1F3
H
(SN)
1F2
H
(SC)
1F1
H
(FR)
xx
xx
xx
xx
xx
At command completion (I/O registers contents to be read)
1F7
H
(ST) Status information
1F6
H
(DH)
×××
DV xx
1F5
H
(CH)
1F4
H
(CL)
1F3
H
(SN)
1F2
H
(SC)
1F1
H
(ER)
xx
xx
xx
xx
Error information
Note:
Also executable in LBA mode.
(10) SEEK (X’7x’, x : X’0’ to X’F’)
This command performs a seek operation to the track and selects the head
specified in the command block registers. After completing the seek operation,
the device clears the BSY bit in the Status register and generates an interrupt.
The IDD always sets the DSC bit (Drive Seek Complete status) of the Status
register to 1.
In the LBA mode, this command performs the seek operation to the cylinder and
head position in which the sector is specified with the logical block address.
