BIOS Setup- 43 -
English
Onboard Serial Port 1
Auto BIOS will automatically setup the Serial port 1 address.
3F8/IRQ4 Enable onboard Serial port 1 and address is 3F8/IRQ4. (Default value)
2F8/IRQ3 Enable onboard Serial port 1 and address is 2F8/IRQ3.
3E8/IRQ4 Enable onboard Serial port 1 and address is 3E8/IRQ4.
2E8/IRQ3 Enable onboard Serial port 1 and address is 2E8/IRQ3.
Disabled Disable onboard Serial port 1.
Onboard IrDA Port
Auto BIOS will automatically setup the IrDA port address.
3F8/IRQ4 Enable onboard IrDA port and address is 3F8/IRQ4.
2F8/IRQ3 Enable onboard IrDA port and address is 2F8/IRQ3.(Default value)
3E8/IRQ4 Enable onboard IrDA port and address is 3E8/IRQ4.
2E8/IRQ3 Enable onboard IrDA port and address is 2E8/IRQ3.
Onboard Parallel Port
Disabled Disable onboard LPT port.
378/IRQ7 Enable onboard LPT port and address is 378/IRQ7. (Default value)
278/IRQ5 Enable onboard LPT port and address is 278/IRQ5.
3BC/IRQ7 Enable onboard LPT port and address is 3BC/IRQ7.
Parallel Port Mode
SPP Using Parallel port as Standard Parallel Port. (Default value)
EPP Using Parallel port as Enhanced Parallel Port.
ECP Using Parallel port as Extended Capabilities Port.
ECP+EPP Using Parallel port as ECP and EPP mode.
ECP Mode Use DMA
3 Set ECP Mode Use DMA to 3. (Default value)
1 Set ECP Mode Use DMA to 1.
CIR Port Address
310 Set CIR Port Address to 310.
320 Set CIR Port Address to 320.
Disabled Disable this function. (Default value)
CIR Port IRQ
5 Set CIR Port IRQ to 5.
11 Set CIR Port IRQ to 11. (Default value)
On-Chip USB
Disabled Disable this function if you are not using onboard USB function.
V1.1+V2.0 Enable USB 1.1 and USB 2.0 controller. (Default value)
V1.1 Enable only USB 1.1 controller.
Legacy USB Keyboard/Storage
Enabled Enable USB keyboard support in the MS-DOS environment.
Disabled Disable this function. (Default value)
Legacy (DOS) USB Mouse
Enabled Enable USB mouse support in the MS-DOS environment.
Disabled Disable this function. (Default value)
