Removal and Replacement Procedures
Maintenance and Service Guide 5–69
2. Remove the display lid switch module by firmly pulling it
off the fan/heat sink assembly.
✎
The display lid switch module is secured to the fan/heat sink
assembly by 2-sided tape. Apply removal force to the middle of
the module to remove it.
Removing the Display Lid Switch Module
✎
The display lid switch module cable is included with the
display lid switch module spare part kit and is also included in
the Cable Kit, spare part number 434677-001.
Reverse the above procedure to install the display lid
switch module.
