WLAN module
Description Spare part
number
802.11a/b/g WLAN module for use in Canada and the United States 407160-001*
802.11a/b/g WLAN module for use in the People's Republic of China, Ecuador, Haiti, Honduras,
Pakistan, Peru, Qatar, South Korea, Uruguay, and Venezuela
407160-002*
802.11b/g WLAN module for use in Argentina, Brazil, Canada, Chile, Mexico, Taiwan, and the United
States
407159-001
802.11b/g WLAN module for use in the People's Republic of China, Ecuador, Haiti, Honduras, Pakistan,
Peru, Qatar, South Korea, Uruguay, and Venezuela
407159-002
802.11b/g WLAN module for use in the US 441090-001**
802.11b/g WLAN module for use in the People's Republic of China, Ecuador, Haiti, Honduras, Pakistan,
Peru, Qatar, South Korea, Uruguay, and Venezuela
441090-002**
802.11a/b/g WLAN module for use in the US 441075-001
802.11a/b/g WLAN module for use in the People's Republic of China, Ecuador, Haiti, Honduras,
Pakistan, Peru, Qatar, South Korea, Uruguay, and Venezuela
441075-002
* For use with F500–F549 models
** For use with F550–F579, G6000 models
Before removing the WLAN module, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power cord.
4.
Remove the battery (see
Battery on page 29).
5.
Remove the memory module compartment cover (see
Memory module on page 32).
Remove the WLAN module:
1.
Position the computer with the front toward you.
2. Disconnect the WLAN antenna cables (1) from the WLAN module.
NOTE: The black WLAN antenna cable is connected to the WLAN module “Main” terminal. The
gray WLAN antenna cable is connected to the WLAN module “Aux” terminal.
3. Remove the two Phillips PM2.0×3.0 screws (2) that secure the WLAN module to the computer. (The
edge of the module opposite the socket rises away from the computer.)
